Pylontech US5000 48V 4.8kWh Modular Lithium Battery
Pylontech US5000 48V 4.8kWh Modular Lithium Battery

Pylontech US5000 48V 4.8kWh Modular Lithium Battery

Regular price $2,945.00 Sale price$2,345.00
/
Tax included.
  • In stock, ready to ship
  • Backordered, shipping soon


This site is protected by hCaptcha and the hCaptcha Privacy Policy and Terms of Service apply.


Pylontech Battery Info:

US5000-B

US5000 is the latest Pylontech 48V LFP battery with bigger capacity at 4.8kWh modular and stronger functions for high current strike endurance, dual active protection, remote upgrade feature, widely internal compatibility up to 16 modules per single string.

Parameter Value
Nominal Voltage (VDC) 48
Nominal Capacity (kWh) 4.8
Usable Capacity (kWh) 4.56
Dimension (WDH mm) 442 * 420 * 165
Weight (kg) 40
Depth of Discharge 95%
Charge/Discharge (A) (Normal) 50
Charge/Discharge (A) (Max) 74~89@69S
Charge/Discharge (A) (Peak) 90~200@15S
Communication Port RS485/CAN
Single String Quantity (pcs) 16
Working Temperature (℃) Charge 0~50
Working Temperature (℃) Discharge -10~50
Storage Temperature (℃) -20~60
Short current/duration time (A) <4000/2ms
IP rating IP20
Humidity (RH) 5%~95% No condensation
Altitude (m) <4000
Design life (@25℃) 10+ years
Cycle Life (@25℃) >6,000
Certification IEC62619/IEC63056/IEC61000-6-2/3/UN38.3
