STCs = -$792.00
-
Solar Victoria = -$1,000.00
-
VEECs = -$420.00
Low GWP Refrigerant
Our Heat Pump Water Heater uses R290 which has a global warming potential (GWP) of 3. Many heat pumps use R134A. R290 has a global warming potential that is 476 times lower than R134A. As many refrigerants are strong greenhouse gases, the use of refrigerants with low GWP is seen as a way to minimise the effect of refrigeration systems on global warming.
Eco Mode
Eco mode optimizes the benefits of Solar PV and lower cost, time-of-use electricity.The Solar optimisation mode (PV) and time-of use mode (HC) receive a communication signal from an energy management control system (if you have an existing Solar PV system). Alternatively, a timer is used to set heating to the low cost periods of a time-of-use tariff.
Longevity
Using patented technology with a triple layer protection creates a long lasting, acid and alkali corrosion resistant inner tank. The inner tank is tested to over 160,000 cycles to ensure durability over the expected lifetime.
Connected
Built in Wi-Fi module and SmartHQ™ allows control of the appliance from anywhere. Change between five user modes at the tip of your fingers by opening SmartHQ™ on your smartphone.
Capacity
Total water capacity:195L
Features
Anode type:Magnesium
Ingress protection:IPX4
Performance
Ambient temperature working limits (Heat Pump only):-7°C to 45°C
Ambient temperature working limits (Total appliance):-7°C to 45°C
Heat pump refrigerant mass:0.34kg
Heat pump refrigerant type:R290
Maximum output water temperature (Heat pump only):65°C
Maximum output water temperature (Total appliance):75°C
Noise emissions:43dB
Plumbing Installation
Expansion control valve (max pressure):600kPa
Pressure limiting valve setting (max pressure):500kPa
Pressure temperature relief valve:700kPa
Power requirements
Electric element power input:1.5kW
Maximum power input (Heat pump input):0.75kW
Maximum power input (Total appliance):2.25kW
Rated Power input (Heat pump):0.43kW
Supply frequency:50Hz
Supply voltage:220-240V
Product dimensions
Depth:630mm
Height:1658mm
Packaged depth:695mm
Packaged height:1940mm
Packaged weight:116kg
Packaged width:736mm
Product weight:91kg
Product weight (filled):286kg
Width:600mm
Rebates
STC entitlements
Warranty
Inner cylinder only:7 years
Inner cylinder only (Commercial):1 year
Parts and labour:5 years
Parts and labour (Commercial):1 year
